Important points for mesh analysis
Important points
for mesh analysis
- While assuming loop currents make sure that atleast one loop current links with every element.
- No two loops should be identical.
- Choose minimum number of loop currents.
- Convert current source if present into their equivalent voltage sources for loop analysis whenever possible
- If current in a particular branch is required, then’try to choose loop current in such a way that only one loop current links with that branch.
